Dimensional
Data

1.54

2014 (U1 REVISED)

Arch 1

8/0 Lip Lite Grille Locations

A

D

E

A

D

A

B

C

D

Panel

Glass

A

B

C

D

2/8

22 x 64

9-3/8"

22-7/16"

10-5/8"

65-3/4"

2/10

22 x 64

10-3/8"

23-7/16"

10-5/8"

65-3/4"

3/0

22 x 64

11-3/8"

24-7/16"

10-5/8"

65-3/4"

GBG - Lip Lite - 8'0" 3/4 Lite - 9 Lite Prairie

Panel

Glass

A

B

C

D

2/8

22 x 64

15-7/8"

-

-

38-3/16"

2/10

22 x 64

16-7/8"

-

-

38-3/16"

3/0

22 x 64

17-7/8"

-

-

38-3/16"

GBG - Lip Lite - 8'0" 3/4 Lite -2W2H

Panel

Glass

A

B

C

D

E

2/8

22 x 64

15-7/8"

-

-

27-1/2" 48-13/16"

2/10

22 x 64

16-7/8"

-

-

27-1/2" 48-13/16"

3/0

22 x 64

17-7/8"

-

-

27-1/2" 48-13/16"

GBG - Lip Lite - 8'0" 3/4 Lite - 2W3H

ůůĚŝŵĞŶƐŝŽŶƐƐŚŽǁŶĂƌĞƚŽƚŚĞĐĞŶƚĞƌŽĨƚŚĞŵƵŶƟŶ͘
