Dimensional
Data

1.62

2014 (U1 REVISED)

Arch 1

6/8 Flush-Glazed Grille Locations

B

C

D

E

F

G

A

B

C

D

E

F

A

Panel

Glass

A

B

C

D

E

F

2/6

20 x 64

14-7/8"

11-3/8"

18-7/16" 20-13/16" 36-15/16"

53"

2/8

20 x 64

15-7/8"

12-3/8"

19-7/16" 20-13/16" 36-15/16"

53"

*2/10

25 x 64

16-7/8"

13-1/4"

22-5/16" 20-7/8" 36-15/16" 53-1/16"

3/0

27 x 64

17-7/8"

13-3/8"

22-7/16" 20-7/8" 36-15/16" 53-1/16"

GBG - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 3W4H and 2W4H

*Only available in 6/6.

Panel

Glass

A

B

C

D

E

F

2/6

20 x 64

14-7/8"

11-3/8"

18-7/16" 20-11/16" 36-3/4" 52-13/16"

2/8

20 x 64

15-7/8"

12-3/8"

19-7/16" 20-11/16" 36-3/4" 52-13/16"

2/10

25 x 64

16-7/8"

13-1/4"

22-5/16" 20-11/16" 36-3/4"

52-7/8"

3/0

25 x 64

17-7/8"

14-1/4"

23-5/16" 20-11/16" 36-3/4"

52-7/8"

GBG - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 3W4H and 2W4H

ůůĚŝŵĞŶƐŝŽŶƐƐŚŽǁŶĂƌĞƚŽƚŚĞĐĞŶƚĞƌŽĨƚŚĞŵƵŶƟŶ͘

Panel

Glass

A

B

C

D

E

F

G

2/6

20 x 64

14-7/8"

11-1/2"

18-5/16" 17-13/16" 30-9/16"

43-1/4"

56"

2/8

20 x 64

15-7/8"

12-1/2"

19-5/16" 17-13/16" 30-9/16"

43-1/4"

56"

2/10

25 x 64

16-7/8" 12-13/16"

21"

17-13/16" 30-9/16"

43-1/4"

56"

3/0

25 x 64

17-7/8" 13-13/16"

22"

17-13/16" 30-9/16"

43-1/4"

56"

Wood Grilles - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 3W5H and 2W5H

Panel

Glass

A

B

C

D

E

F

G

2/6

20 x 64

14-7/8"

11-1/2"

18-5/16" 17-11/16" 30-3/8"

43-1/8" 55-13/16"

2/8

20 x 64

15-7/8"

12-1/2"

19-5/16" 17-11/16" 30-3/8"

43-1/8" 55-13/16"

2/10

25 x 64

16-7/8" 12-13/16"

21"

17-11/16" 30-3/8"

43-1/8" 55-13/16"

3/0

25 x 64

17-7/8" 13-13/16"

22"

17-11/16" 30-3/8"

43-1/8" 55-13/16"

Wood Grilles - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 3W5H and 2W5H

Panel

Glass

A

B

C

D

E

F

G

2/6

20 x 64

14-7/8"

11-3/8"

18-7/16" 17-5/8"

30-1/2"

43-5/16" 56-3/16"

2/8

20 x 64

15-7/8"

12-3/8"

19-7/16" 17-5/8"

30-1/2"

43-5/16" 56-3/16"

*2/10

25 x 64

16-7/8" 12-11/16" 21-1/8"

17-5/8"

30-1/2"

43-5/16" 56-3/16"

3/0

27 x 64

17-7/8"

13-3/8"

22-7/16" 17-5/8"

30-1/2"

43-3/8"

56-1/4"

GBG/SDL - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 3W5H and 2W5H

*Only available in 6/6.

Panel

Glass

A

B

C

D

E

F

G

2/6

20 x 64

14-7/8"

11-3/8"

18-7/16" 17-7/16" 30-5/16" 43-3/16"

56"

2/8

20 x 64

15-7/8"

12-3/8"

19-7/16" 17-7/16" 30-5/16" 43-3/16"

56"

2/10

25 x 64

16-7/8" 12-11/16" 21-1/8"

17-7/16" 30-5/16" 43-3/16"

56"

3/0

25 x 64

17-7/8" 13-11/16" 22-1/8"

17-7/16" 30-5/16" 43-3/16"

56"

GBG/SDL - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 3W5H and 2W5H
