Dimensional
Data

Arch 1

2014 (U1 REVISED)

1.23

Unit and Rough Opening Sizing

SL

Inswing

(Viewed from the exterior)

Hand Designations

L

R

Left Hand

Right Hand

SR

LS

RS

S

Vented Sidelite
(hinged off jamb)

47 3/4"

49 3/4"

51 3/4"

53 3/4"

55 3/4"

46"

48"

50"

52"

54"

Unit Dimension

45 1/4"

47 1/4"

49 1/4"

51 1/4"

53 1/4"

80 1/

2"

79 3/

4"

79 1/

4"

82 7/8"

82"

81 5/

8"

98 7/8"

98"

97 5/8"

Rough Opening

Brickmould Dim.

Single with Venting Sidelite - Wide Mullion

Single with 14" Venting Sidelite - Wide Mullion - 6/6, 6/8, 8/0
