Unit and rough opening sizing, Single with venting sidelites - wide mullion – Therma-Tru ARCH 1 Dimensional Data - U1 Revised User Manual

Page 25

background image

Dimensional
Data

Arch 1

2014 (U1 REVISED)

1.25

Unit and Rough Opening Sizing

63 7/16"

65 7/16"

67 7/16"

69 7/16"

71 7/16"

61 11/16"

63 11/16"

65 11/16"

67 11/16"

69 11/16"

Unit Dimension

60 15/16"

62 15/16"

64 15/16"

66 15/16"

68 15/16"

80 1/

2"

79 3/

4"

79 1/

4"

82 7/

8"

82"

81 5/

8"

98 7/8"

98"

97 5/8"

Rough Opening

Brickmould Dim.

Single with Venting Sidelites - Wide Mullion

Single with 2-14" Venting Sidelites - Wide Mullion - 6/6, 6/8, 8/0

SLS

Inswing

(Viewed from the exterior)

Hand Designations

L

R

Left Hand

Right Hand

SRS

S

Sidelite
