Dimensional
Data

Arch 1

2014 (U1 REVISED)

1.27

SLRS

Inswing

L

R

Left Hand

Right Hand

(Viewed from the exterior)

Hand Designations

A

Astragal

S

Sidelite

SLAS

SARS

Unit and Rough Opening Sizing

92 1/8"

96 1/8"

100 1/8"

104 1/8"

108 1/8"

90 3/8"

94 3/8"

98 3/8"

102 3/8"

106 3/8"

Unit Dimension

89 5/8"

93 5/8"

97 5/8"

101 5/8"

105 5/8"

80 1/

2"

79 3/

4"

79 1/

4"

82 7/

8"

82"

81 5/8"

98 7/8"

98"

97 5/

8"

*Outswing not available.

French with 2-14" Venting Sidelites - Wide Mullion 6/6, 6/8, 8/0

Rough Opening

Brickmould Dim.

French with Venting Sidelites - Wide Mullion
