Dimensional
Data

1.28

2014 (U1 REVISED)

Arch 1

Unit and Rough Opening Sizing

37 5/8"

13 1/2"

15 1/2"

13 7/16"

Single Transoms

Unit Dimension

*Add actual unit dimension to door rough opening height for total rough opening height.

Double - Standard Continuous Mullion Transoms

62 13/16"

66 13/16"

70 13/16"

74 13/16"

13 7/

16"

13 5/

8"

Unit Dimension

*Add actual unit dimension to door rough opening height for total rough opening height.

63 5/8"

67 5/8"

13 7/

16"

13 5/8"

31 13/16"

33 13/16"

Unit Dimension

*Add actual unit dimension to door rough opening height for total rough opening height.

Single with 2 Sidelites - Continuous Transoms

64 5/8"

68 5/8"

13 7/

16"

13 5/

8"

32 5/

16"

34 5/16"

Unit Dimension

*Add actual unit dimension to door rough opening height for total rough opening height.

Single with 2 Sidelites - Boxed Transoms
