ELECTRICAL DATA
UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
UNIT
549B
NOMINAL
VOLTAGE
(V-Ph-Hz)
VOLTAGE
RANGE
COMPRESSOR
OFM
IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max
RLA
LRA
FLA
FLA
kW†
FLA
MCA
MOCP
FLA
LRA
036
(3 Tons)
208/230-1-60
187
254
16.0
88.0
0.7
4.9
—
/—
—
/—
25.6/ 25.6
30/ 30**
25/ 25 101/101
3.3/ 4.4
15.9/18.3
45.5/ 48.5
50/ 50**
43/ 46 117/120
4.9/ 6.5
23.6/27.1
55.1/ 59.5
60/ 60**
52/ 56 125/128
6.5/ 8.7
31.3/36.3
64.7/ 71.0
70/ 80
61/ 67 133/138
7.9/10.5
38.0/43.8
73.1/ 80.4
80/ 90
69/ 75 139/145
9.8/13.0
47.1/54.2
84.5/ 93.4
90/100
79/ 87 148/155††
208/230-3-60
187
254
10.3
77.0
0.7
4.9
—
/—
—
/—
18.5/ 18.5
20/ 20**
18/ 18
90/ 90
3.3/ 4.4
9.2/10.6
30.0/ 31.7
30/ 35**
29/ 30
99/101
4.9/ 6.5
13.6/15.6
35.5/ 38.0
40/ 40**
34/ 36
104/106
6.5/ 8.7
18.0/20.9
41.0/ 44.6
45/ 45**
39/ 42
108/111
7.9/10.5
21.9/25.3
45.9/ 50.1
50/ 60**
43/ 47
112/116
12.0/16.0
33.3/38.5
60.1/ 66.6
70/ 70
57/ 63
124/129
460-3-60
414
508
5.1
39.0
0.4
2.2
—
—
9.0
15**
9
46
6.0
7.2
18.0
20**
17
53
8.8
10.6
22.2
25**
21
57
11.5
13.8
26.2
30**
25
60
14.0
16.8
30.0
30**
28
63
048
(4 Tons)
208/230-1-60
187
254
23.7
129.0
0.7
4.9
—
/—
—
/—
35.2/ 35.2
40/ 40**
34/ 34
142/142
3.3/ 4.4
15.9/18.3
55.1/ 58.1
60/ 60**
52/ 55
158/161
6.5/ 8.7
31.3/36.3
74.4/ 80.6
80/ 90
70/ 75
174/179
9.8/13.0
47.1/54.2
94.1/103.0
100/110
88/ 96
189/196††
13.1/17.4
63.0/72.5
114.0/125.9
125/150
106/117
205/215††
15.8/21.0
76.0/87.5
130.2/144.6
150/150
121/134
218/230††
208/230-3-60
187
254
13.5
99.0
0.7
4.9
—
/—
—
/—
22.5/ 22.5
25/ 25**
22/ 22
112/112
4.9/ 6.5
13.6/15.6
39.5/ 42.0
40/ 45**
38/ 40
126/128
6.5/ 8.7
18.0/20.9
45.0/ 48.6
45/ 50**
43/ 46
130/133
12.0/16.0
33.3/38.5
64.1/ 70.6
70/ 80
60/ 66
146/151
15.8/21.0
43.9/50.5
77.4/ 85.6
90/100
72/ 80
156/163
460-3-60
414
508
7.4
49.5
0.4
2.2
—
—
11.9
15**
12
57
6.0
7.2
20.9
25**
20
64
11.5
13.8
29.1
30**
27
70
14.0
16.8
32.9
35**
31
73
23.0
27.7
46.5
50**
43
84
060
(5 Tons)
208/230-1-60
187
254
28.8
169.0
1.5
8.8
—
/—
—
/—
46.3/ 46.3
50/ 50**
45/ 45
216/216
4.9/ 6.5
23.6/27.1
75.8/ 80.2
80/ 90
72/ 76
240/243
6.5/ 8.7
31.3/36.3
85.4/ 91.7
90/100
81/ 87
247/252††
9.8/13.0
47.1/54.2
105.2/114.1
110/125
99/107
263/270††
13.1/17.4
63.0/72.5
125.1/136.9
150/150
117/128
279/289††
15.8/21.0
76.0/87.5
141.3/155.7
150/175
132/146
292/304††
208/230-3-60
187
254
17.3
123.0
1.5
5.8
—
/—
—
/—
28.9/ 28.9
30/ 30**
28/ 28 168/168
4.9/ 6.5
13.6/15.6
45.9/ 48.4
50/ 50**
44/ 46 181/183
7.9/10.5
21.9/25.3
56.3/ 60.6
60/ 70
53/ 57 190/193
12.0/16.0
33.3/38.5
70.6/ 77.1
80/ 80
67/ 73 201/208
15.8/21.0
43.9/50.5
83.8/ 92.1
90/100
79/ 86 212/218††
19.9/26.5
55.2/63.8
97.9/108.7
100/110
92/102 223/232††
460-3-60
414
508
9.0
62.0
0.8
2.6
—
—
14.7
15**
14
84
6.0
7.2
23.7
25**
23
92
11.5
13.8
31.9
35**
30
98
14.0
16.8
35.7
40**
34
101
23.0
27.7
49.3
50**
46
112
25.5
30.7
53.0
60**
50
115
072
(6 Tons)
208/230-3-60
187
254
20.5
156.0
1.4
5.8
—
/—
—
/—
32.8/ 32.8
35/ 35**
32/ 32
200/200
4.9/ 6.5
13.6/15.6
49.8/ 52.3
50/ 60**
47/ 50
214/216
7.9/10.5
21.9/25.3
60.2/ 64.5
70/ 70
57/ 61
222/225
12.0/16.0
33.3/38.5
74.5/ 81.0
80/ 90
70/ 76
233/239
15.8/21.0
43.9/50.5
87.7/ 96.0
90/100
82/ 90
244/251††
19.9/26.5
55.2/63.8
101.8/112.6
110/125
95/105
255/264††
460-3-60
414
508
9.6
70.0
0.6
2.6
—
—
15.2
20**
15
92
6.0
7.2
24.2
25**
23
99
11.5
13.8
32.5
35**
31
106
14.0
16.8
36.2
40**
34
109
23.0
27.7
49.8
50**
47
120
25.5
30.7
53.6
60**
50
123
