GUIDE SPECIFICATIONS — 542J150,180 UNITS

PACKAGED ROOFTOP AIR-TO-AIR HEAT PUMP — CON-
STANT VOLUME APPLICATION
HVAC GUIDE SPECIFICATIONS

SIZE RANGE: 12 to 15 TONS, NOMINAL (COOLING)

136,000 to 172,000 BTUH, NOMINAL
(INPUT HEATING)

BRYANT MODEL NUMBER: 542J

PART 1 — GENERAL
1.01 SYSTEM DESCRIPTION

Outdoor rooftop mounted, electrically controlled air-to-air
heat pump unit utilizing reciprocating, semi-hermetic com-
pressor(s) for cooling duty and electric resistance coils for
heating duty. Unit shall discharge supply air vertically or
horizontally (with horizontal supply/return adapter assem-
bly or roof curb) as shown on contract drawings.

1.02 QUALITY ASSURANCE

A. Unit shall be rated in accordance with ARI Standard 340.

Designed in accordance with UL Standard 1995.

B. Unit shall be designed to conform to ASHRAE 15, latest

revision.

C. Unit shall be UL-tested and certified in accordance

with ANSI Z21.47 Standards and UL-listed and certified
under Canadian standards as a total package for safety
requirements.

D. Roof curb shall be designed to conform to NRCA

Standards.

E. Insulation and adhesive shall meet NFPA 90A require-

ments for flame spread and smoke generation.

F. Unit casing shall be capable of withstanding 500-hour salt

spray exposure per ASTM B117 (scribed specimen).

G. Unit shall be designed in accordance with ISO 9001, and

shall be manufactured in a facility registered to ISO 9002/
BS5750, Part 2.

H. Each unit shall be subjected to a completely automated

run testing on the assembly line. Units contain a factory-
supplied printout indicating tested pressures, amperages,
data, and inspectors; providing certification of the unit
status at the time of manufacture.

1.03 DELIVERY, STORAGE, AND HANDLING

Unit shall be stored and handled per manufacturer’s
recommendations.

PART 2 — PRODUCTS
2.01 EQUIPMENT (STANDARD)

A. General:

Factory assembled, single-piece heat pump unit. Con-
tained within the unit enclosure shall be all factory wiring,
piping, controls, refrigerant charge (R-22), and special
features required prior to field start-up.

B. Unit Cabinet:

1. Unit cabinet shall be constructed of galvanized steel,

and shall be bonderized and coated with a pre-
painted baked enamel finish on all externally
exposed surfaces.

2. Indoor fan compartment interior cabinet surfaces

shall be insulated with a minimum

-in. thick, 1 lb.

density, flexible fiberglass insulation, neoprene
coated on the air side.

3. Cabinet panels shall be easily removable for

servicing.

4. Holes shall be provided in the base rails for rigging

shackles to facilitate maneuvering and overhead
rigging.

5. Unit shall have a factory-installed, sloped conden-

sate drain pan made of a non-corrosive material, pro-
viding a minimum

-in. 14 NPT connection with both

vertical and horizontal drains, and shall comply with
ASHRAE Standard 62.

6. Unit shall have a factory-installed filter access panel

to provide filter access with tool-less removal.

7. Unit shall have standard thru-the-bottom power con-

nection capability (accessory kit is required).

C. Fans:

1. Indoor Fan:

a. Fan shall be belt driven with an adjustable-pitch

motor pulley. The standard fan drive shall have a
factory-installed low-medium static pressure fan
drive. The alternate fan drive option shall have a
factory-installed high static pressure fan drive.

b. Fan wheel shall be double-inlet type with forward-

curved blades.

c. Bearings shall be sealed, permanently lubricated

ball-bearing type for longer life and lower
maintenance.

d. Bearings shall be pillow block type (180 only).

2. Indoor fan shall be made from steel with a corrosion-

resistant finish and shall be dynamically balanced.

3. Outdoor fan shall be of the direct-driven (with totally

enclosed motors) propeller type and shall discharge
air vertically.

4. Outdoor fan shall have aluminum blades riveted to

corrosion-resistant steel spiders and shall be dynam-
ically balanced.

D. Compressor(s):

1. Reciprocating semi-hermetic compressors with

factory-installed crankcase heaters.

2. Factory mounted on rubber grommets and internally

spring mounted for vibration isolation.

3. On independent circuits (180).

4. The size 150 unit semi-hermetic compressor shall be

equipped with an electric unloader for capacity
control.

E. Coils:

1. Standard indoor and outdoor coils shall have copper

or aluminum plate fins mechanically bonded to
seamless internally grooved copper tubes with all
joints brazed.

2. Coils:

a. Copper-fin coils shall be constructed of copper

fins mechanically bonded to copper tubes and
copper tube sheets. Galvanized steel tube sheets
shall not be acceptable. A polymer strip shall pre-
vent coil assembly from contacting the sheet
metal coil pan to minimize potential for galvanic
corrosion between coil and pan. All copper con-
struction shall provide protection in moderate
coastal environments.
