- 9 -
Register addresses:
The function of the registers in the Module depends on the type of the controller (TC+1,
TC+2, TC+4) in which the module is used. Detailed descriptions of the functions can be
found in the manuals of the different controllers. Here you can find the list of addresses at
the different types of controllers: See: TC+1 below; TC+2 page 12; TC+4 page 15
ThermoControl-Plus 1
*0000h: Hi: Controller type code (35h),
Lo: Version number.
0002h: No
function
0004h: Disable or enable buttons individually. Detailed in Appendix.
0006h: Simulation of pushing a button . Detailed in Appendix.
0008h: Special button combinations. Detailed in Appendix.
000Ah: Simulation of releasing a button.
000Ch: in Zone 1 control is enabled (On) or disabled (Off), 1: On, 0: Off
000Eh: in Zone 2 control is enabled (On) or disabled (Off), 1: On, 0: Off
0010h: No
function
0012h: No function
0014h: No
function
0016h: No function
0018h: No
function
001Ah: No function
001Ch: Set value type selection in Zone 1:
0000h:
Based on time program,
0001h: Frost
protection
value (continuously)
0002h:
Night value (continuously)
0003h:
Day value (continuously)
001Eh: Set value type selection in Zone 2: same as described at Zone 1
0020h: No
function
0022h: No
function
0024h: No function
0026h: No function
0028h: No
function.
002Ah: No function
002Ch: Zone1 Day set value ×10 with plus/minus sign.
Example: 00C7h 19.9°C
002Eh: Zone2 Day set value ×10 with plus/minus sign.
0030h: No
function
0032h: No
function
0034h: No
function
0036h: No
function
0038h: No
function
003Ah: No
function
003Ch: Zone1 Night set value ×10 with sign.
003Eh: Zone2 Night set value ×10 with sign.
0040h: No
function
0042h: No
function
0044h: No
function
The *-marked addresses are “Read-only” types
