- 12 -

ThermoControl-Plus 2

*0000h: Hi: Controller type code (36h),

Lo: Version number.

0002h: No

function

0004h: Disable or enable buttons individually. Detailed in Appendix.
0006h: Simulation of pushing a button . Detailed in Appendix
0008h: Special button combinations. Detailed in Appendix
000Ah: Simulation of releasing a button.
000Ch: in Zone 1 control is enabled (On) or disabled (Off), 1: On, 0: Off

000Eh: in Zone 2 control is enabled (On) or disabled (Off), 1: On, 0: Off
0010h: in Zone 3 control is enabled (On) or disabled (Off), 1: On, 0: Off
0012h: in Zone 4 control is enabled (On) or disabled (Off), 1: On, 0: Off
0014h: No function
0016h: No

function

0018h: No

function

001Ah: No function
001Ch: Set value type selection in Zone 1:

0000h:

Based on time program,

0001h: Frost

protection

value (continuously)

0002h:

Night value (continuously)

0003h:

Day value (continuously)

001Eh: Set value type selection in Zone 2: same as described at Zone 1
0020h: Set value type selection in Zone 3: same as described at Zone 1
0022h: Set value type selection in Zone 4: same as described at Zone 1
0024h: No function
0026h: No function
0028h: No

function

002Ah: No function
002Ch: Zone1 Day set value ×10 with plus/minus sign.

Example: 00C7h 19.9°C

002Eh: Zone2 Day set value ×10 with plus/minus sign
0030h: Zone3 Day set value ×10 with plus/minus sign
0032h: Zone4 Day set value ×10 with plus/minus sign
0034h: No

function

0036h: No

function

0038h: No

function

003Ah: No

function

003Ch: Zone1 Night set value ×10 with plus/minus sign
003Eh: Zone2 Night set value ×10 with plus/minus sign
0040h: Zone3 Night set value ×10 with plus/minus sign
0042h: Zone4 Night set value ×10 with plus/minus sign
0044h: No

function

0046h: No

function

0048h: No

function

004Ah: No

function

004Ch: Zone1 Frost protection value ×10 with sign. This value acts as a low limit for all

of the other set values. Factory settings: 0050h 8.0°C

004Eh: Zone2 Frost protection value ×10 with sign
0050h: Zone3 Frost protection value ×10 with sign

The *-marked addresses are “Read-only” types
