Technical data
Target group: Operating authority, operators
Machine type designation: RM200
Use according to the intended purpose
This machine is not designed as a production machine but as
laboratory equipment, intended for an 8 hours single shift
operation with 30% operating time.
The RM200 is suitable for dry and wet milling of soft, medium
hard, hard, pasty and brittle materials, up to a hardness of 9
on the Mohs’ scale.
Furthermore quantities of approx. 10 to 190 ml and a max.
charging grain size of 8 mm can be ground and homogenised
with the RM200, without manual use of force.
A final fineness of down to 0.01 mm (10 µm), and in individual
cases even below this value, can be achieved with the RM200.
Do not make any alterations to the machine and use only
spare parts and accessories approved by Retsch.
Otherwise the Declaration of Conformity with the
European Directives by Retsch loses its validity.
Furthermore this will result in the loss of any kind
of guarantee claim.
Emissions
Noise characteristic values :
Noise measurement according to DIN 45635-031-01-KL3
Intensity of sound L
WA
= 85 dB(A)
Emission value related to workplace L
pAeq
= 72 dB(A)
Operating conditions:
Material to be milled = quartz sand, grain size < 1 mm
Protective system: IP53
Rated power: 230 Watt
Machine dimensions
Height: 480 mm up to approx. 550 mm with lid opened
Width: 400 mm
Depth : 370 mm up to approx. 510 mm with lid opened
Weight: approx. 24 kg without mortar and pestle
Required floor space
400 mm x 400 mm plus space at the rear for the opened
lid. No safety distance required.
