Operating elements and their function
General plan
Element Description Function
A Machine socket Connection for power cable of machine
B Fuse compartment Takes two visible type fuses
C Type plate Information on the machine and connected
loads
D ON/OFF switch For switching the RM200 on and off
E Display and operating unit: For
explanations see below
Time preselection and starting / stopping the
machine
F Closing grip For opening and locking the millling chamber
G Turning handle – pestle pressure
adjustment
Turning alters the pestle contact pressure
H Scale Setting guide for pestle pressure
I Filling opening Sample material is filled here
J Viewing window Viewing possibility during the milling
process, particularly for adjusting the
scraper
K Setting knob for scraper Sets the contact pressure or gap of scraper
L Pestle setting knob For adjusting the pestle on the mortar wall
M Hood Closes the milling chamber
