Count!Guard Manual 35
4.1.2.2 Delete camera
To delete a camera, execute the following steps:
 Select a camera in the Added cameras panel.
 Click <
Your camera has been deleted.
4.1.2.3 Edit & Configure camera (Counting Algorithm)
4.1.2.3.1 Camera and Positioning requirements
Before we can start the camera configuration, check first if the following requirements are met. Not
meeting these requirements may lead to inaccurate counts and abnormal behavior of the
Count!Guard application.
Requirements:
 The camera is positioned higher than 2,50 meters ( >8.2 feet).
 The camera is mounted vertically (horizontal and vertical deviation angle = 0°). This means
it is looking straight down.
The vertical deviation angle may go up to 30° but can influence the counting accuracy.
The vertical angle is the angle measured in the flow direction of the moving persons.
 The camera delivers +/-25 fps to the WebCCTV server
 The image resolution has to be at least QVGA (320x240) and preferably VGA (640x480).
 Lighting conditions: daylight or similar lighting.
 The camera streams in JPEG
4.1.2.3.2 Camera Configuration
In normal circumstances, a basic camera configuration is enough to get accurate counts.
Execute the following steps for a basic configuration:
 Select a camera in the Added cameras panel.
 Click Start Configuration Utility.
 New windows will open. You need the MvApplications Configurations Tools and
Parameters Pallet window. The other ones may be minimized or closed.
Information and explanation about parameters can be found in the Help pallet.
