Pistol grip installation guide
Pistol Grip Installation Guide
Installing Pistol Grip
1.Line up Pistol Grip on indicated line of PDT.
2.Use four screws to affix Pistol Grip on PDT.
Ensure Pistol Grip is secured correctly
before you use it.
Removing Pistol Grip
1.Use screwdriver to loosen four screws
from Pistol Grip.
2.Remove Pistol Grip from PDT.
CAUTION:
!
