SCAN QUANTITY DEMO APPLICATION - PAGE 15
S CAN QUANTITY DEMO OPL9728 OPTICON
2.5 Send data
By selecting the Send data menu the
database if present can be transmitted to the
PC. The protocol and baudrate as set in the
communication menu are used.
The other communication parameters that can
not be changed are:
Parity =
None
Databits = 8
Stopbits = 1
When the transmit data message appears on
the display put the OPL9728 in the cradle and
then press a key. On the PC needs to run an
application to receive the database.
After a successful transmission a message
appears to delete the database. See delete
data for more infromation.
Transmission error during transfer
protocol.
If this message appears transmission is
interrupted. Then retry to transmit the
database to the PC.
