GRAPHICAL DEMO APPLICATION - PAGE 6

PRINT DEMO TEC B-SP2D (B

LUETOOTH

)

2.2 Scroll data

When selecting this menu item it is possible to
scroll through the inputted data and print one
of the stored barcodes.
Unless there is no data available, then this
option will result in a message that there is no
data on the RAM disk.

Use button 1 (back) to return.

Use button 2 to scroll and select a barcode.
After pressing button 2’, progress messages
will start to appear on the display which show
the progress or possible error messages.

Use the trigger button to print the selected
barcode

Note 1: Make sure the printer is on and is
ready to print a bar code (the green LED
should be on) before trying to print a barcode.

Note 2: In the appendix can be read how to
set the bluetooth connection between the
OPL9724 and the TEC B-SP2D bluetooth
printer.
