RESETTING DEVICE

SETTING DEVICE

1. Initial Boot Up

The initial boot up screen will be displayed
when you install the the battery pack for the
first time. Do not remove
when the system is booting.

the battery pack

2. Calibrating Touchscreen

This calibration is already done by the
manufacturer. If you want to calibrate the touch
screen again, please tap “Start” --- “Settings”
--- “Control Panel” --- “Stylus” --- “Calibration"
--- "Recalibrate”, then hold the stylus and press
on the center of the target as it moves around
the screen.

5. Brightness Setting

The device is equipped with backlight for both
sunlight-readable LCD display and keypad.
To adjust the LCD backlight brightness, press
the “Fn” key and then press navigation key
“>” or “<” to adjust display brightness.
Press “Start”---“Settings”---“Control Panel” ---
“Control Center” “Brightness”

both LCD

and keypad brightness.

to set

6. Volume Adjustment

1) Press “Start”---“Settings”---“Control Panel”

-- “Volume & Sounds”.

2) Adjust the volume bar to meet your demand.

To mute the sound, press the “Fn” key and then
press “ESC” key to turn off and on the sound.

Note:

USING THE APPLICATIONS

1. Execute an Application

Tap an application icon on the desktop, or tap

“Start”---“Programs”. Select one of the applications.

2. Close an Application

Tap the “X” to close the application.

3. Using the Software Input Panel

1) Tap the “Stylus” icon on the task bar.
2) Tap the “Keyboard” icon.
3) When the Software Input Panel appears, input

characters with the Stylus.

4. Task Switch

Win CE can execute multiple applications
at the same time.
1) Press “Task Switch” icon in the task bar.
2) Select the task you want in the task menu.
You can use this to bring the selected application to the foreground.
It does not close the other applications.

BAR CODE READING

Remove the protective film from the scan window before use.

1. Start your application
2. Aim the scan window at the bar code
3. Press the scan key.
4. Aiming :

1D laser: aim the red laser beam on the center of the bar code

Bar codes can be read from 50 to 650 mm distance.

USING PERIPHERALS

1. Using a microSD Card

Insert a correctly oriented card.

To remove a microSD card, follow the “Open” and “Lock”
direction to pull out the

Remove the battery cover

2) Remove the Battery Pack.
3)

card

Note:

The microSD slot supports memory cards only. It does not support
SD I/O peripherals.

2. USB Connection

Connect to the Cradle to synchronize data with a computer.

1. Warm Reset

1) If an application hangs, initiate a Warm Reset to terminate

the application.

2) The Warm Reset will close all applications and clear the working

RAM, but all files will be preserved.

3) To perform a Warm Reset, press “F1” and “F4” keys

simultaneously.

CAUTION:

A. Do not stare into the laser beam directly or shine it

into a person s eyes.

B. Never use strong pressure onto the screen or subject

it to severe impact, as the LCD panel could become
cracked and possibly cause personal injury. If the
LCD panel is broken, do not touch the liquid inside,
because the liquid irritates the skin.

C. Use only the original approved AC adapter with the

H-15. Use of an unapproved AC Adapter could
result in electrical problems, or even cause a fire or
electrical shock to the user.

D. Do not disassemble the H-15. Servicing should

be done by authorized suppliers only. If the device
or accessories get damaged due to wrong handling
or unauthorized repair, warranty is void. In case the
warranty seals are broken, warranty is void, too.

E. Make regular backups of all important data.
F. Under no circumstance will Manufacturer be liable

direct, indirect, consequential or incidental

arising out of use or inability to use both

and software and/or any data loss,

has been informed about the

damages.

’

for any
damages
the hardware
even if Manufacturer
possibility of such

communication

H-15

Quick Guide

huma

nizat

ion

managemen

CAUTION:

Start Button

Close Button

CAUTION:

Be sure to use the supplied stylus or plastic-

tipped pens for the touch screen display. Don't use pencils, pens
or any sharp objects on the touch screen display.

4. Bluetooth Device Properties

Bluetooth

Device Properties to enable the Bluetooth
device.

2) Wait for 20 seconds in order to initialize the

Bluetooth hardware correctly.

) Press the Scan Device button to search for

Bluetooth devices.

Availability depends on H-15 model.

1) Press “Start”---“Programs” -- “

”

Note :

H-15

Keyboard input panel.

2. Cold Reset

H-15

Try

before you initiate a Cold Reset. All

applications will be closed, and working RAM as well as
all files will be cleared if you initiate the Cold Reset. It is
strongly recommended to back up your files to Flash ROM,
Flash Card or PC.

Warm Reset

Task Switch

Stylus/Keyboard icon

1) You can use Cold Reset to initialize the device if the

WinCE.NET OS locks up or in case a Warm Reset has no effect.

2) To perform a Cold Reset, press “Power”, “F1” and “F4” keys

simultaneously.

3) The device will boot up after the Cold Reset.

5. Check the bar code reading result

You can verify the result of the bar code reading in your application,

by beep sound(s) or the LED indicator.

Good scanning positions

Bad scanning positions

H-15

4615-810001-01

WPP

3. Setting Up Wireless LAN for Summit

)

Enable Wireless LAN by clicking on the

WLAN icon on the main screen.

2) Wait until the SCU icon appears on the task

bar and then click on it to start the

"Summit Client Utility".

Set the AP then press the Connect button

to connect it

3 In the Profile tab tap the Scan button to

connect/refresh the network.

4) Select a network, tap the Connect button or

double tap it to create a new profile SSID

Availability depends on H-15 model.

Note:

Do not throw this product in the home waste bin.

User and Product Safety
