4.0
LED INDICATORS
4.1
Switch Module
Each 4-Port Switch Module has LED indicators to provide connection
information.
4 Port Switch Module
LED Function
Color
Off State
ON State
Power "Pwr"
Yellow
No Power
On: Module has Power
Port 1 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 1 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 2 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 2 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 3 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 3 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
Port 4 "100 Link"
Green
Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 4 "10 Link"
Green
Not Linked at 10Mbps
On: Port Linked at 10Mbps
Blinking: Data Activity
4 Port Switch Module LED Indicators
