4.0 LED INDICATORS
4.1 Switch Module
Each 4-Port Switch Module has LED indicators to provide connection
information.
4 Port Switch Module
LED Function Color OFF State ON State
Power "Pwr" Yellow No Power On: Module has Power
Port 1 "100 Link" Green Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 1 "10 Link" Green Not Linked at 10Mbps On: Port Linked at 10Mbps
Blinking: Data Activity
Port 2 "100 Link" Green Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 2 "10 Link" Green Not Linked at 10Mbps On: Port Linked at 10Mbps
Blinking: Data Activity
Port 3 "100 Link" Green Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 3 "10 Link" Green Not Linked at 10Mbps On: Port Linked at 10Mbps
Blinking: Data Activity
Port 4 "100 Link" Green Not Linked at 100Mbps On: Port Linked at 100Mbps
Blinking: Data Activity
Port 4 "10 Link" Green Not Linked at 10Mbps On: Port Linked at 10Mbps
Blinking: Data Activity
4 Port Switch Module LED Indicators
Page 8
5.0 SPECIFICATIONS
Description 8 Port 10/100 Auto-Sensing Switch
Protocols 10Base-T, 100Base-Tx,
with 1536 bytes max. frame size
UTP Cable Type EIA/TIA 568A/B
Category 5 and higher
UTP Connector Type RJ45
DIP-Switches UTP Port 1 and 2: AN/MAN, 10/100, FD/HD
Power Requirements +/- 18 to 60VDC
-48VDC @ 1.0A
Dimensions W:6.7" x D:5.51" x H:1.87"
Weight 3.0 lbs
Compliances UL, CE, FCC CLass A, NEBS Level 3
Temperature Operating: 0 to +50 C
Storage: -40 to +80 C
Humidity
(non-condensing)
< 95%
Altitude (operational) < 4000m (13,000 ft)
