0 introduction, 1 general description, 2 chassis models – Omnitron Systems Technology FlexSwitch 6530 FK User Manual
Page 3: Introduction, General description, Chassis models, Installation
1.0
INTRODUCTION
1.1
General Description
The 6530-FK is the direct replacement for the discontinued FlexSwitch Model
600XC 4Fx. The 6530-FK replacement kit consists of two iConverter Fast
Ethernet Fiber-to-Fiber Media Converter Modules installed in an iConverter 2-
Module chassis.
The 6530-FK provides four 100Base-Fx fiber ports supporting half or full duplex
operation.
The 6530-FK features front panel accessible DIP-Switches for convenient
configuration of the fiber ports. On-board DIP-Switches configure the link
mode and backplane operation. The backplanes are enabled by default.
1.2
Chassis Models
FlexSwitch Replacement Matrix
Discontinued Part
Replacement Part
6530-0
6530-0-FK
6530-2
6530-2-FK
6530-3
6530-3-FK
6531-0
6531-0-FK
6531-2
6531-2-FK
Replacement Matrix
FlexSwitch Model 6530
Fiber Type
Distance
Connector Type
SC
ST
MM
5km
6530-0-FK
6531-0-FK
SM
30km
6530-2-FK
6531-2-FK
SM
60km
6530-3-FK
-
Model Numbers
Page 3
