1.0
INTRODUCTION
1.1
General Description
The 6550-FK is the direct replacement for the discontinued FlexSwitch
Model 600XC 1Fx + 4U. The 6550-FK replacement kit consists of one
iConverter 10/100Base-Tx to 100Base-Fx Media Converter Module and
one iConverter 4Tx Switch Module installed in a iConverter 2-Module
Chassis.
The 6550-FK provides auto-negotiating 10/100 UTP ports with auto-crossover
that enables easy attachment to hubs, switches and workstations. The
100Base-Fx fiber port supports half or full duplex operation.
The 6550-FK features on-board and front panel accessible DIP-Switches for
manual configuration of the ports.
1.2
Chassis Models
FlexSwitch Replacement Matrix
Discontinued Part
Replacement Part
6550-0
6550-0-FK
6550-2
6550-2-FK
6550-3
6550-3-FK
6551-0
6551-0-FK
6551-2
6551-2-FK
Replacement Matrix
FlexSwitch Model 6550
Fiber Type
Distance
Connector Type
SC
ST
MM
5km
6550-0-FK
6551-0-FK
SM
30km
6550-2-FK
6551-2-FK
SM
60km
6550-3-FK
-
Model Numbers
Page 3
