Omnitron Systems Technology FlexPoint Gx User Manual
Omnitron Systems Technology Communication

Auto-Negotiation switch is in the “Disable” position). The
recommended mode is “Full-duplex” (factory setting).
“Pause” Switch:
This switch controls the “Pause” advertising of the
FlexPoint Gx preferred mode of operation (when the
Auto-Negotiation switch is in the “Disable” position). The
recommended mode is “Enable” (factory setting).
“Link Isolate / Link Propagate” Switch:
When set to the “Link Prop.” (factory setting), the link
state is propagated from the UTP port to the fiber port
and visa versa. This allows the loss of link to be
propagated and detected by SNMP or other network
managed devices and it facilitates Spanning-Tree
network reconfiguration during a cable failure.
When set to “Link Isolate” the generation and detection
of link presence is done at each point-to-point segment.
It should be noted that when in “Link Prop.” mode, the
absence of received UTP link causes the transmitted
fiber link to be turned off. The absence of received fiber
link causes both the transmit and receive UTP link to be
turned off. This mechanism prevents a “deadly
embrace” when both links are absent initially during
power-up and configuration.
LED Indicators:
LED
Color
Description
Power
Yellow
Power applied
FDX/HDX
Yellow
On - Full-Duplex
Off - Half Duplex
F/O Link/Rx
Green
Fiber Link / Data Received
UTP Link/Rx
Green
UTP Link / Data Received
Warning
The operating description in this Instruction Manual is
for use by qualified personnel only. To avoid electrical
shock, do not perform any servicing of this unit other
than that contained in the operating instructions, unless
you are qualified and certified to do so by Omnitron
Systems Technology, Inc.
Caution
All user-required operations can be performed without
opening the unit. Never attempt to open or remove the
cover or tamper with the unit.
Warranty
This product is warranted to the original purchaser against
defects in material and workmanship for a period of TWO
YEARS from the date of shipment. A LIFETIME warranty
may be obtained by the original purchaser by REGISTERING
this product with Omnitron within 90 days from the date of
shipment. TO REGISTER, COMPLETE AND MAIL OR FAX
THE REGISTRATION PORTION OF THIS INSTRUCTION
MANUAL TO THE INDICATED ADDRESS. Or you may
register your product on the internet at http://
www.omnitron-systems.com. During the warranty period,
Omnitron will, at its option, repair or replace a product which
is proven to be defective.
For warranty service, the product must be sent to an Omnitron
designated facility, at Buyer’s expense. Omnitron will pay
the shipping charge to return the product to Buyer’s
designated US address using Omnitron’s standard shipping
method.
Limitation of Warranty
The foregoing warranty shall not apply to defects
resulting from improper or inadequate use and/or
maintenance of the equipment by Buyer, Buyer-supplied
equipment, Buyer-supplied interfacing, unauthorized
modifications or tampering with equipment (including
removal of equipment cover by personnel not specifically
authorized and certified by Omnitron), or misuse, or
operating outside the environmental specification of the
product (including but not limited to voltage, ambient
temperature, radiation, unusual dust, etc.), or improper
site preparation or maintenance.
No other warranty is expressed or implied. Omnitron
specifically disclaims the implied warranties of
merchantability and fitness for any particular purpose.
Exclusive Remedies
The remedies provided herein are the Buyer’s sole and
exclusive remedies. Omnitron shall not be liable for any
direct, indirect, special, incidental, or consequential
damages, whether based on contract, tort, or any legal
theory.
User Warranty Registration
Please register on-line
@ http://www.omnitron-systems.com
or complete both sides
and mail or fax this registration form to:
FlexPoint
T
ype: Gx, Fiber
T
ype:_______Connector: _______
Model:
_________________________________________________
Serial Number: ______________ Purchase Date:
______________
Purchased From: _________________________________________
Address:
______________________________________________
City: ___________________ State: _______ Zip Code:
________
Country:
_______________________________________________
Comments and
Suggestions:
_______________________________
______________________________________________________
______________________________________________________
Please complete both sides of this form
Technical Support:
For help with this product, contact our Tech. Support:
Phone:
(949) 250-6510
Fax:
(949) 250-6514
Address:
Omnitron Systems Technology, Inc.
27 Mauchly #201
Irvine, CA 92618 USA
E-mail:
URL:
http://www.omnitron-systems.com
Form: 040-04370-001-B 10/03
User Warranty Registration
Please register on-line
@ http://www.omnitron-systems.com
or complete both sides
and mail or fax this registration form to:
Omnitron Systems T
echnology
, Inc.
27 Mauchly #201
Irvine, CA 92618, USA
Fax: (949) 250-6514
N
a
m
e
:
_________________________________________________
Company:
______________________________________________
Address:
______________________________________________
______________________________________________
City: ___________________ State: _______ Zip Code:
________
Country:
_______________________________________________
Phone: ______________
______ Fax:
_______________________
E-mail:
_________________________________________________
Please complete both sides of this form
FlexPoint
™
Gx User Instructions
Description:
The FlexPoint Gx converts between Gigabit Ethernet
fiber 1000Base-X (Sx/Lx) and 1000Base-T twisted pair
(RJ45 UTP) cabling. The following multimode (MM)
and single-mode (SM) models are described here:
Model
Fiber Type
MaxDistance
Type
4370
850 nm (MM)
220 m / 720 ft.
SC
4371
1310 nm (SM)
10 km / 6.2 mi.
SC
4372
1310 nm (SM)
25 km / 15.5 mi.
SC
4373
1550nm (SM)
65 km / 40.4 mi.
SC
4670
850 nm (MM)
220 m / 720 ft.
MT-RJ
4671
1310 nm (SM)
10 km / 6.2 mi.
MT-RJ
4673
1310 nm (SM)
10 km / 6.2 mi.
LC
4674
1310 nm (SM)
25 km / 15.5 mi.
LC
4675
1550nm (SM)
65 km / 40.4 mi.
LC
Power Adapter Notice:
1. When using in a stand-alone configuration, this product
is intended to be and must be used only with a
Listed Direct Plug-In Power Unit marked “Class 2”
and rated at 9VDC, 1 Amp.
2. This product should only be used only with Omnitron
Supplied Power Unit model number 9113-PS.
Mounting and Cable Attachment:
The FlexPoint Gx can be stand-alone-mounted using a
wall-mounting kit (model 4380). It can also be rack-
mounted using a 5-position shelf (Model 4392) or a
high-density 14-unit FlexPoint Powered Chassis (AC
powered model 4395 or 48VDC powered model 4385).
Attach the FlexPoint Gx UTP via a category 5 or higher
cable to a 1000Base-T Ethernet device.
Attach the FlexPoint Gx fiber via a single-mode or
multimode (as needed) cable to a 1000Base-X Gigabit
Ethernet device (make sure to use the correct wavelegth
source for the model being used). The FlexPoint transmit
(Tx) must attach to the receive side on other device; the
receive (Rx) must attach to the transmit.
Switch Settings:
“Auto-Negotiation” Switch:
Setting the switch to “Enable” (factory setting) enables the
UTP port to determine the duplex and pause modes
automatically. Setting the switch to “Disable” causes the
mode of the Duplex and Pause switches to be advertised
to the connected device. The recommended mode is
“Enable” (factory setting).
“Full Duplex/Half Duplex” Switch:
This switch controls the half/full-duplex advertising of the
FlexPoint Gx preferred mode of operation (when the
WARNING!
Before inserting the Power Adapter, verify
that the power on the unit is appropriate
for your AC line voltage source.
