Omnitron Systems Technology miConverter S-Series - Manual (Page 2)

LED Function
“Legend”
Color OFF State ON/Blinking State
Power
“PWR”
Green No power ON: Module has power
Fiber Link Activity
“F/O”
Green No fiber link
ON: Fiber link
Blinking: Data activity
UTP Link Activity
“10”
Green No UTP link
ON: Port linked at 10M
Blinking: Data activity
UTP Link Activity
“1000”
Green No UTP link
ON: Port linked at 1000M
Blinking: Data activity
UTP Link Activity
“10” and “1000”
Green No UTP link
ON: Port linked at 100M
Blinking: Data activity
Specifications
Model miConverter S/GXT miConverter S/FXT
Description
1000BASE-X Fiber to
10/100/1000BASE-T UTP Converter
100BASE-FX Fiber to
10/100/1000BASE-T UTP Converter
Protocols
10BASE-T, 100BASE-TX, 1000BASE-T,
1000BASE-X
10BASE-T, 100BASE-TX, 1000BASE-T,
100BASE-FX
Frame Size 10,240 byte max frame size
Compliance UL, CE, FCC 15 Class B
UTP Cable EIA/TIA 568A/B, Cat 5 and higher
Fiber Cable
Multimode:
Single-mode:
50/125, 62.5/125, 100/140um
9/125um
Copper Connector RJ45
Fiber Connector
SFP:
Dual Fiber:
Single-Fiber:
LC
SC, ST
SC
LED Display Pwr, F/O, UTP
Dimensions W: 1.75” x L: 2.25” x H: 0.84”
Weight
without AC/DC adapter:
with USB cable:
with AC/DC adapter (US) and USB:
2.5 oz.
3.8 oz.
5.4 oz.
DC Power Input
Connector
USB Micro-B
DC Power
Requirements
0.5A @ 5VDC
AC Power
Requirements (US)
100-120VAC
50-60Hz
0.02A @ 120V
AC Power
Requirements (Univ.)
100-240VAC
50-60Hz
0.02A @ 120VAC
Temperature
Standard:
Wide:
Storage:
0 to 50°C
-40 to 65°C
-40 to 80°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4000m
MTBF (hrs)
without AC/DC adapter:
US AC/DC adapter:
Univ AC/DC adapter:
1,300,000
50,000
200,000
Page 2 Page 3
Ordering Information
Fiber
Type
Distance
Connector Type
ST ST Metal SC SFP (LC)
miConverter S/FXT Fast Ethernet Fiber Media Converter
SFP - - - - 1619-0-x
MM/DF 5km 1600-0-x 1600M-0-x 1602-0-x -
SM/DF 30km 1601-1-x 1601M-1-x 1603-1-x -
SM/SF* 20km - - 1610-1-x -
SM/SF* 20km - - 1611-1-x -
miConverter S/GXT Gigabit Ethernet Fiber Media Converter
SFP - - - - 1639-0-x
MM/DF 220m/550m 1620-0-x 1620M-0-x 1622-0-x -
SM/DF 12km 1621-1-x 1621M-1-x 1623-1-x -
SM/DF 34km - - 1623-2-x -
SM/SF* 20km - - 1630-1-x -
SM/SF* 20km - - 1631-1-x -
When choosing power options, replace (-x) in the model number with the suffix
number that corresponds to the selected power adapter.
-1 Includes US AC/DC power adapter and USB power cable
-1T Includes US AC/DC power adapter, USB power cable and travel case
-3 Includes European AC/DC power adapter and USB power cable
-4 Includes UK AC/DC power adapter and USB power cable
-5 Includes Australian AC/DC power adapter and USB power cable
-6 NO AC/DC power adapter. Includes USB power cable
-6T NO AC/DC power adapter. Includes USB power cable and travel case
-8 Includes Japan AC/DC power adapter and USB power cable
-8T Includes Japan AC/DC power adapter, USB power cable and travel case
Example: 1623-2-4 = SM / DF / 34km with UK AC/DC power adapter and USB power
cable.
*Single-Fiber converters must be used in pairs. The Tx wavelength on one end has to
match the Rx wavelength on the other. For wide temperature models (-40 to 65° C), add
a “W” to the end of the model number. Contact Omnitron for other configurations.
Model No. Description
9146-1 Spare US/USB AC/DC adapter and 3ft. USB power cable
9146-3 Spare Euro/USB AC/DC adapter and 3ft. USB power cable
9146-4 Spare UK/USB AC/DC adapter and 3ft. USB power cable
9146-5 Spare Aus/USB AC/DC adapter and 3ft. USB power cable
9146-8 Spare Japan/USB AC/DC adapter and 3ft. USB power cable
9146-6 3ft. USB power cable (standard Type A plug to micro-B plug)
1691-0 miConverter S-Series wall mount bracket
1692-0 Spare miConverter S-Series travel case
