Ordering inFOrmatiOn
Page 2
800-675-8410 • 949-250-6510 • www.omnitron-systems.com • [email protected] • 140 Technology Dr., Irvine, CA 92618
iConverter 10/100
© 2012 Omnitron Systems Technology, Inc. All rights reserved. iConverter and NetOutlook are Registered Trademarks of Omnitron Systems Technology, Inc.
Trademarks are owned by their respective companies. Specifications are subject to change without notice.
091-18380-007M 2/12
speciFicatiOns management
Management is accomplished by using a Network Management
Module (NMM2) or a media converter with integrated management
(such as an iConverter 10/100M2) that provides monitoring,
remote configuration and trap notification. The management
module can be accessed via SNMP, Telnet and via a serial
port. The SNMP-based management is accomplished via
Omnitron’s intuitive, graphic-oriented NetOutlook management
software or third party SNMP management software, while the
Telnet and the serial interfaces have an easy-to-use, menu-
driven interface.
Some of the real-time 10/100 parameters that can be monitored
include power, link and data receive status. Other parameters
include module type and model, hardware and software
revisions, serial numbers, and an user-defined identifier.
The user can override the 10/100 module’s physical
DIP-switch settings using SNMP or Telnet to remotely configure
DIP-switch-selectable parameters such as auto-negotiation,
Half/Full-Duplex, Link Mode selection, and Ethernet Backplane
selection.
In addition to all standard
iConverter SNMP traps such as
module insertion and removal, the 10/100 modules can
generate traps on port state changes including link-up and
link-down. Trap monitoring of specific events can be selectively
enabled or disabled by the network administrator.
Model Type 10/100
Protocols
100BASE-FX, 10BASE-T,
or 100BASE-TX
UTP Connectors RJ-45
Fiber Connectors SC, ST, LC, Single-Fiber SC
Controls
UTP X-over, LS/LP, RFD, Auto/Man,
10/100, FDX/HDX
LED Displays
Power, FO link, UTP link, Auto,
UTP FDX/HDX, F/O FDX/HDX, 10, 100
Dimensions W:0.85" x D:4.5" x H:2.8"
Weight 8 oz.
Compliance UL, CE, FCC Class A, NEBS Level 3
Power Requirement 0.95A @ 3.3VDC (typical)
Temperature
Standard: 0 to 50º C
Wide: -40 to 60º C
Storage: -40 to 80º C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4000m
MTBF (hrs) 1,050,000
Model Type
Fiber /
Media
Type
Distances
Connector Types Tx
Wavelength
(nm)
Rx
Wavelength
(nm)
Min. Tx
Power
(dBm)
Max. Tx
Power
(dBm)
Min. Rx
Sensitivity
(dBm)
Max. Rx
Sensitivity
(dBm)
Link
Budget
(dBm) ST SC LC
10/100
Dual Fiber
MM 2km 8380-6 8382-6 - 850 850 -10 -4 -24 -3 14
MM 5km 8380-0 8382-0 8386-0 1310 1310 -24 -14 -31 -14 7
SM 30km 8381-1 8383-1 8387-1 1310 1310 -15 -8 -31 -8 16
SM 60km 8381-2 8383-2 8387-2 1310 1310 -5 0 -31 -3* 26
SM 120km - 8383-3 8387-3 1550 1550 -5 0 -31 -3* 26
10/100
Single-Fiber
SM 20km - 8390-1 - 1310 1550 -15 -5 -30 -3 15
SM 40km - 8390-2 - 1310 1550 -8 0 -30 -3* 22
SM 60km - 8390-3 - 1310 1550 -5 0 -31 -3* 26
SM 20km - 8391-1 - 1550 1310 -15 -5 -30 -3 15
SM 40km - 8391-2 - 1550 1310 -8 0 -30 -3* 22
SM 60km - 8391-3 - 1550 1310 -5 0 -31 -3* 26
For wide temperature (-40 to 60º C), add a "W" to the end of the model number. Consult factory for extended temperature (-40 to +75º C) models and other fiber
configurations. When using single-fiber (SF) media converter models, the Tx wavelength on one end has to match the Rx wavelength on the other.
*A minimum of 3dB of attenuation is required for these models.
