Readout of Stored Test Results
The analyzer memory is automatically transferred to the PC and visualized
through small screenshots on the MiniLINK memory window.
Note: The MiniLINK memory window remains empty when no test
results are stored on the instrument. Otherwise, use the PC
mouse to click onto the “AL1 Memory“ tab to initiate and update
the data memory window.
The test instrument display on the PC is synchronized to the actual LCD
screen display of the connected audio analyzer. The title bar shows the
serial number and firmware version of the test instrument.
Synchronized Display
MiniLINK PC
Software Release
Version
Firmware of
connected audio
analyzer
Serial Number of
connected audio
analyzer
