TECHNICAL SPECIFICATIONS
FULL METAL HOODS DTSL-SERIES
Ordering information:
MHDTSL-SL-TOP
Size: P/N - Kitted: Product Code:
9-way-TOP 3560-0100-31 DTSL09-SL-T-K
MHDTSL-SL-SIDE
Features:
● Slide-Lock Version
● Available in size 9 only
● Excellent EMI Shielding
● Re-openable
MHDTSL-SL-TOP MHDTSL-SL-SIDE
Material: Zinc, Nickel Plated
Operating Temperature: -40°C to +120°C
Cable Entry:
Top or Side Entry
Cable O.D: Up to 11,5mm
Assembly Instruction: See page 204
Size: P/N - Kitted: Product Code:
9-way-SIDE 3560-0200-31 DTSL09-SL-S-K
Size: P/N - BULK: Product Code:
9-way-TOP 3561-0100-31 DTSL09-SL-T
Size: P/N - BULK: Product Code:
9-way-SIDE 3561-0200-31 DTSL09-SL-S
Accessories:
Cable O.D: P/N - Kitted: Product Code:
4,5-5,5mm 3544-0001-01 DMZK09-4.5-D1
5,5-6,5mm 3544-0001-02 DMZK09-6.0-D1
6,5-8,0mm 3544-0001-03 DMZK09-7.0-D1
8,0-9,0mm 3544-0001-04 DMZK09-8.5-D1
Rubber Grommet +
Metal Support Ferrule Kit
