Ordering information:
Size: P/N - Kitted: Product Code:
9-way 6560-06 X 6-11 D45ZK09-CZK-K
15-way 6560-06 X 6-12 D45ZK15-CZK-K
25-way 6560-06 X 6-13 D45ZK25-CZK-K
37-way 6560-06 X 6-14 D45ZK37-CZK-K
Size: P/N - BULK: Product Code:
9-way 6561-06 X 6-11 D45ZK09-CZK
15-way 6561-06 X 6-12 D45ZK15-CZK
25-way 6561-06 X 6-13 D45ZK25-CZK
37-way 6561-06 X 6-14 D45ZK37-CZK
Size MHD45ZK Dim A Dim B Dim C
9-way 31,0 36,3 14,5
15-way 39,5 40,3 14,5
25-way 53,2 40,3 14,5
37-way 69,7 40,3 14,5
TECHNICAL SPECIFICATIONS
Example: (Size 15 with 7,5mm Ferrule Kit)
6560-06 2 6-02 D45ZK15-CZK-K
Max Cable Body: Ring:
O.D. (mm) Dy / Di Dy / Di Order Code X :
6,0 5,0 / 4,0 7,0 / 6,0 1
7,5 7,0 / 6,0 9,0 / 8,0 2
8,5 8,0 / 7,0 10,0 / 9,0 3
9,5 9,0 / 8,0 11,0 / 10,0 4
FULL METAL HOODS D45ZK-CZK-SERIES
Material: Zinc, Nickel Plated
Brass Ferrule / Brass Ring
Operating Temperature: -40°C to +120°C
Cable Entry:
45° Side Entry
Thumbscrews: UNC 4-40 (Standard)
M2,5 or M3 on request
Cable O.D: Up to 9,5mm
Accessories: See page 190-194
Assembly Instruction: See page 201
Features:
● Available in sizes 9-15-25-37
● Excellent EMI Shielding
● Re-openable
● Strain relief inserts ensure a secure termination
● Full Metal Jackscrew as standard
