Power Connectors M 23 / Inserts / Pinouts
Dimensions and specifications may be changed without prior notice
Contact Arrangement, Mating View Type of Contact Part Number
6 x crimp pins 2 mm ......................................................... 7.084.951.101
6 x crimp sockets 2 mm ..................................................... 7.084.951.102
4 x crimp pins 1 mm
4 x crimp pins 2 mm
......................................................... 7.084.943.101
4 x crimp sockets 1 mm
4 x crimp sockets 2 mm ..................................................... 7.084.943.102
5 x crimp pins 1 mm *
4 x crimp pins 2 mm * ....................................................... 7.084.953.101
5 x crimp sockets 1 mm *
4 x crimp sockets 2 mm * ................................................... 7.084.953.102
10 x crimp pins 1 mm ....................................................... 7.084.910.101
10 x crimp sockets 1 mm ................................................... 7.084.910.102
* Assembly instructions see page 122
