114 Dimensions and specifications may be changed without prior notice
Crimp pin 1 mm, machined 0,14 – 1 mm 2 .....................7.010.941.001
(AWG 26 – 17)
Crimp socket 1 mm, machined 0,14 – 1 mm 2 .....................7.010.941.002
(AWG 26 – 17)
Crimp pin 2 mm, machined 0,75 – 2,5 mm 2 ..................7.010.942.001
(AWG 18 – 14)
Crimp pin 2 mm, machined 2,5 – 4 mm 2 .......................7.010.942.011
(AWG 14 – 12)
Power Connectors M 23 / Contacts
See page 128 for crimp tool instructions and proper setting
Crimp socket 2 mm, machined 0,75 – 2,5 mm 2 ..................7.010.942.002
(AWG 18 – 14)
Crimp socket 2 mm, machined 2,5 – 4 mm 2 .......................7.010.942.012
(AWG 14 – 12)
Crimp pin 1 mm, machined 0,75 – 1,5 mm 2 ..................7.010.941.021
(AWG 18 – 16)
Crimp pin 1 mm, machined 0,75 – 1,5 mm 2 ..................7.010.941.022
(AWG 18 – 16)
Contacts Type Crimp Range Part Number
