124
8.
9.
1.
2.
3.
6.
7.
5.
4.
!
10.
Dimensions and specifications may be changed without prior notice
Right Angle Connector, rotating
Power Connectors M 23 / Assembly Instructions
65 mm
crimp
click click
27
24
25
x
Contact 1 mm = 4 mm
Contact 2 mm = 7 mm
x
