Northern Connectors Hummel M23-Power - Circular Connectors - Manual (Page 18)

122
1. 5.
2.
3.
4. 6.
8.
7.
!
1.
Dimensions and specifications may be changed without prior notice
Contact 1 mm = 4 mm
Contact 2 mm = 7 mm
x
Straight Connector, Female Thread 5+3+PE
click
crimp
24
24
click click
click
click
max. 37
mm
x
Power Connectors M 23 / Assembly Instructions
