Power Connectors M 23 / Assembly Instructions
Dimensions and specifications may be changed without prior notice
Right Angle Panel Connector
x
crimp
click click
300°
x
Contact 1 mm = 4 mm
Contact 2 mm = 7 mm
SW 2
SW 1,5
