Northern Connectors Hummel M23-Power - Circular Connectors - Manual (Page 7)

M 23 x 1
37,5 37,5
PG 13,5
26
6
Ø 20,6 + 0,1
20,6+ 0,1
19,3
+
0,1
37,5
6
M 20 x 1,5
M 23 x 1
26
Ø 20,2 + 0,1
20,2+ 0,1
19,1
+
0,1
M 25 x 1,5
32,5
M 23 x 1
7
28
Ø 25,2 + 0,1
25+ 0,1
24,1
+
0,1
M 23 x 1
M 25 x 1,5
37,3 33,8
30
29
Ø 25 + 0,1
25+ 0,1
24,1
+
0,1
111 Dimensions and specifications may be changed without prior notice
Contacts and inserts page 113 • Assembly instructions page 126
Rear mounting
Thread M 25 x 1,5 .............7.651.000.000
Including jam nut M 25 x 1,5
Panel Connector, Male Thread, Single Hole Mounted
Panel Connector, Male Thread, Single Hole Mounted
Type Part Number
Contacts and inserts page 113 • Assembly instructions page 126
Front mounting
Thread M 25x1,5 ...............7.626.000.000
Options:
Flat gasket, jam nut M 25 x 1,5
Type Part Number
Contacts and inserts page 113 • Assembly instructions page 126
Front mounting
Thread PG 13,5 .................7.623.000.000
Options:
Flat gasket, jam nut PG 13,5
Type Part Number
Contacts and inserts page 113 • Assembly instructions page 126
Front mounting
Thread M 20 x1,5 ..............7.621.000.000
Options:
Flat gasket, jam nut M 20 x 1,5
Type Part Number
Panel Connector, Male Thread, Single Hole Mounted
Panel Connector, Male Thread, Single Hole Mounted
Power Connectors M 23 / Housing
Panel hole
Panel hole
Panel hole
Panel hole
max.
8 mm
