Northern Connectors Hummel M23-Power - Circular Connectors - Manual (Page 4)

24 24
71,8
M 23 x 1
24
71,8
43,8 24,6
M 23 x 1
Ш 26 Ш 3,2
35
28,4
24 24
77,55
Ш 27,2
108
24 24
76,4
Ш 28
7 – 12 mm (.27 – .47“).......7.560.500.000
11 – 17 mm (.43 – .67“).....7.560.600.000
7 – 12 mm (.27 – .47“).......7.550.500.000
11 – 17 mm (.43 – .67“).....7.550.600.000
Dimensions and specifications may be changed without prior notice
Contacts and inserts page 113 • Assembly instructions page 121
Cable-Ø Part Number Straight Connector, Male Thread
4 holes Ø 3,2 mm (.13“), front or rear mounting
7 – 12 mm (.27 – .47“).......7.683.500.000
11 – 17 mm (.43 – .67“).....7.683.600.000
Contacts and inserts page 113 • Assembly instructions page 121
Cable-Ø Part Number Panel Connector, Male Thread, with Strain Relief
Contacts and inserts page 113 • Assembly instructions page 121
Cable-Ø Part number Straight Connector, Female Thread
Contacts and inserts page 113 • Assembly instructions page 121
Cable-Ø Part number Straight Connector, Female Thread TWILOCK / TWILOCK-S *
Power Connectors M 23 / Housing
7 – 12 mm (.24 – .47“).......7.556.500.000
11 – 17 mm (.43 – .67“).....7.556.600.000
* Compatible to Speedtec
7 – 12 mm (.24 – .47“).......7.556.500.00S
11 – 17 mm (.43 – .67“).....7.556.600.00S
Panel hole
min. Ш 26,5 + 0,2
