Northern Connectors Hummel M23-Power - Circular Connectors - Manual (Page 8)

19,8
Ш 2,7
25
5
34,5
54,7
Ш 20 + 0,1
M20x1,5
47,1
54,7
M23x1
7,6
Ø 20,2 + 0,1
Pg13,5
47,1
54,7
M23x1
7,6
Ш 20,6 + 0,1
Ш 20 + 0,1
Ш 2,7 Ш 3,2 19,8
25
22,6
28
2,5
41,2
54,7
112 Dimensions and specifications may be changed without prior notice
Contacts and inserts page 113 • Assembly instructions page 127
300° rotating, locking screw at flange
4 x holes Ø 2,7 mm (.11“) ..7.638.000.000
Flange 25 x 25 mm
4 x holes Ø 3,2 mm (.13“) ..7.638.100.000
Flange 28 x 28 mm
Type Part Number Right Angle Panel Connector, Male Thread, rotating
Contacts and inserts page 113 • Assembly instructions page 127
335° rotating, single hole mounted
Thread PG 13,5 .................7.637.000.000
Type Part Number Right Angle Panel Connector, Male Thread, rotating
Contacts and inserts page 113 • Assembly instructions page 127
335° rotating, single hole mounted
Thread M 20 x 1,5 .............7.636.000.000
Type Part Number Right Angle Panel Connector, Male Thread, rotating
Contacts and inserts page 113 • Assembly instructions page 127
4 holes Ø 2,7 mm (.11“) .....7.635.000.000
Options:
Flat gasket
Easy fastening with M 2,5 x 10 mm or 4 x .39“ long screws
Type Part Number Right Angle Panel Connector, Male Thread
Power Connectors M 23 / Housing
Panel hole
Panel hole
Panel hole
Panel hole
