These values are only guidelines and actual conductor cross sections depend on manufacturer tolerances.
Dimensions and specifications may be changed without prior notice
Crimp Tool Setting for HUMMEL Crimp Contacts (Crimp Tool 7.000.900.901)
Crimp Tool for Power Connectors M 23
Part Number Crimp Contact Cross Section mm 2 AWG Crimp Tool Setting mm Locator Setting
7.010.941.021 Crimp socket (power) 1 mm 0,75 18 0,79 1
1 17 0,86 1
1,5 16 0,99 1
7.010.941.002 Crimp socket (power) 1 mm 0,14 26 0,75 2
0,25 24 0,8 2
0,35 22 0,85 2
0,50 20 0,89 2
0,75 18 0,95 2
1 17 1,02 2
7.010.941.022 Crimp socket (power) 1 mm 0,75 18 0,79 2
1 17 0,86 2
1,5 16 0,99 2
7.010.942.001 Crimp pin (power) 2 mm 0,75 18 1,3 7
1 17 1,4 7
1,5 16 1,55 7
2,5 14 1,7 7
7.010.942.011 Crimp pin (power) 2 mm 2,5 14 1,47 7
4 12 1,6 7
7.010.942.002 Crimp socket (power) 2 mm 0,75 18 1,3 8
1 17 1,4 8
1,5 16 1,55 8
2,5 14 1,7 8
7.010.942.012 Crimp socket (power) 2 mm 2,5 14 1,47 8
4 12 1,6 8
Please see assembly instructions on page 128
