Technical Data
Power Connectors M 23
Materials and Technical Data
Mechanical Data
Electrical Data
Housing
Copper-Zinc alloy
Die Cast
Housing surface
Nickel plated
other surface upon request
Inserts (for contacts)
Thermoplastic Polyamid PA 6 (Nylon 6/6), PBT
Fire protection class V-0
Contacts
Brass Alloy
Contact surface at point of contact
Nickel and gold plated (0,25 μm Au)
Minimum mating cycles
> 1000
Seals / O-Rings
Buna-N standard
optional Viton
®
(Viton is a registered trademark of DuPont)
Temperature range
-40° C – 125° C (-40 °F – 257 °F)
Type of contacts
Crimp
Protection
IP 67 / IP 69 K per EN 60 529 (connected), NEMA 4x
Cable diameter range
7 – 17 mm (.28 – .67“)
Dimensions and specifications may be changed without prior notice
Number of positions
Number of contacts
Contact-Ø [mm]
Nominal current
1)
[A]
Nominal voltage
2
) [V~] Degree of Protection 3
3)
Test voltage (Breakdown voltage)
4)
[V~]
Insulation resistance [mΩ]
Max. contact resistance [mΩ]
1), 2), 3), 4)
See Technical Informations page 14
5 + PE
4 + 3 + PE
5 + 3 + PE
10
6
4
4
5
4
10
2
1
2
1
2
1
28
8
28
10
28
10
600
300
600
250
630
160
4000
2500 4000
2500 4000
2500
> 10
13
> 10
13
> 10
13
> 10
13
3
3
3
3
