Page 49

New Era Pump Systems Inc.

www.SyringePump.com

Model NE-500/NE-501 Multi-Phaser™

Publication #1200-02

09/18/14

Pusher block makes a snap or click sound when the pump is started: This is a normal condition. When
the pusher block is manually moved, the drive-nut may not have been fully engaged on the drive screw. The
sound heard is the drive-nut engaging on the drive screw.

Pump doesn’t stop after dispensing a set volume: The pump was previously setup with a multiple Phase
Pumping Program. To simply dispense a fixed volume at a fixed pumping rate, the second Program Phase
must be the ‘Stop’ function. See section 7.1, How to Enter Pumping Programs, for instructions on changing the
Pumping Program.

Pump stops pumping after a period of time: A dispense target volume has been set. Verify that the dispense
target volume is set to 0.

10.5 Specifications

10.5.1

Mechanical & Electrical

Syringe sizes:

Up to 60 mL (140 mL partially filled)

Number of syringes:

Motor type:

Step motor

Motor steps per revolution:

400

Microstepping:

1/8 to 1/2 depending on motor speed

Advance per step:

0.2126

µm to 0.8504 µm depending on motor speed

Motor to drive screw ratio:

15/28

Drive screw pitch:

20 revolutions/”

Power connector:

2.1 mm, center positive, DC

Voltage at power connector:

12 VDC at full load

Amperage:

800 mA at full load

Power supply type:

Unregulated linear external wall adapter, country and power
source specific (or compatible regulated power supply)

Dimensions:

9 1/2” L x 4” W x 4 1/8” (LxWxH)
(24.13 cm x 10.16 cm x 10.5 cm)

Weight:

2.2 lbs. (1.0 kg)

10.5.2

Operational

Maximum speed:

5.1005 cm/min

Minimum speed:

0.004205 cm/hr

Maximum pumping rate:

1699 mL/hr with a B-D 60 mL syringe

Minimum pumping rate:

0.73

µL/hr with a B-D 1 mL syringe

Maximum force:

35 lbs. at minimum speed, 18 lbs. at maximum speed

Number of Program Phases:

RS-232 pump network:

100 pumps maximum

RS-232 selectable baud rates:

300, 1200, 2400, 9600, 19200

Syringe inside diameter range:

0.100 to 50.00 mm

10.6 Custom Applications

For specialized and OEM applications, contact your dealer or
New Era Pump Systems Inc. Custom modifications can be
made to the mechanics or the firmware.
