Model NE-500/NE-501 Multi-Phaser™
Publication #1200-02 35 09/18/14
8.5.4 General Control and Status Commands
TTL I/O OUTPUT SETTING
OUT
E { 1 |2 | 3 | 4 | 5 }
Expansion Port Connector
Sets TTL level on user definable output pin on the ‘TTL I/O’ connector.
Indicates pin number on ‘TTL I/O’ connector
Valid value: 5 (Program Output pin)
E Sets pin on Expansion Port I/O connector on PCB.
Query is not applicable.
TTL INPUT QUERY
IN
E { 1 |2 | 3 | 4 | 5 }
Expansion Port Connector
Queries TTL level of pin on ‘TTL I/O’ connector. Set is not applicable.
Indicates pin number on ‘TTL I/O’ connector
Valid values: 2, 3, 4, and 6.
E Reads from the Expansion Port I/O connector on the PCB.
Query response:
BUZZER
BUZ [ 0 | { 1 [ < n > ] } ]
Sets / queries buzzer
Set: 0 = Turn buzzer off;
1 = Turn buzzer on
if specified
If = 0, buzzer beeps continuously,
otherwise buzzer beeps times
if not specified, buzzer sounds continuously
Query response: { 0 | 1 }
0 = Buzzer off
1 = Buzzer is on continuously or beeping.
8.5.5 System Commands
SET PUMP NETWORK ADDRESS AND BAUD RATE
* ADR [
Set/query pump network address
B { 19200 | 9600 | 2400 | 1200 | 300 } will change the baud rate as indicated. NOTE: The command
response and all further communications will be at the specified baud rate.
Special communications modes
DUAL Sets the pump to Dual Pumping mode with a secondary pump.
RECP Sets the pump to Reciprocating Pumping mode with a secondary pump.
ALTR Sets Alternating pumping mode.
All special communications modes use 19,200 baud rate.
