Output’ TTL line (PHASE 02). After 5.0 mL has been dispensed at 800 mL/hr (PHASE 03), the ‘Program
Output’ TTL line is lowered (PHASE 04), sending a synchronization signal to another device.
The pump then continues to pump at 800 mL/hr (PHASE 06) until a synchronization signal is received at the
‘Event Trigger’ TTL input, causing the Program to jump to Phase 7 (PHASE 05).
The pump then withdraws 0.25 mL (PHASE 07), pauses for 1 second (PHASE 08), then repeats this process if
the Program Input TTL line is low (PHASE 09), otherwise it continues with the next Phase.
Next, the pump pauses for 10 seconds (PHASE 10). Then it pauses again for the lesser of another 10 seconds
(PHASE 12) or until an Event Trigger occurs (PHASE 11). The Program then restarts (PHASE 13).
Phase
Function
1
EVR
Phase
Function
2
OUT 1
Phase
Function
Rate
Volume
Direction
3
RAT
800.0 mL/hr
5.0 mL
Infuse
Phase
Function
4
OUT 0
Phase
Function
5
EVN 07
Phase
Function
Rate
Volume
Direction
6
RAT
800.0 mL/hr
0.0 mL
Infuse
Phase
Function
Rate
Volume
Direction
7
RAT
1000.0 mL/hr
0.25 mL
Withdraw
Phase
Function
8
PAS 01
Phase
Function
9
IF 07
Phase
Function
10
PAS 10
Phase
Function
11
EVN 01
Phase
Function
12
PAS 10
Phase
Function
13
JMP 01
7.4.9
Example 9: Automatic Refill
While a foot switch is held, dispense continuously, starting with a 1.5 mL bolus. When the foot switch is
released, the syringe will refill to the volume that was dispensed.
In the pump’s general setup, set the TTL Trigger to “Foot Switch Hold” mode. Command: TRG FH
Phase
Function
1
TRG 12
Redirect trigger input to the Event Trap
Phase
Function
2
EVN 05
Set Trigger Event Trap to start syringe refill
Phase
Function
Rate
Volume
Direction
3
RAT
1000.0 mL/hr
1.5 mL
Infuse
Begin bolus dispense
