New Era Pump Systems Inc.

www.SyringePump.com

Model NE-500/NE-501 Multi-Phaser™

Publication #1200-02

29

09/18/14

8.3.4

RS-232 Protocol: Basic and Safe Mode Common Syntax

=> { | }

=> [

] []

To pump

=>

[ | ]

From pump

=> { | }

Operational state of pump

=>

I

Infusing

W

Withdrawing

S

Pumping Program Stopped

P

Pumping Program Paused

T

Pause Phase

U

Operational trigger wait (user wait)

X

Purging

=> A ?

Alarm

=>

R

Pump was reset (power was interrupted)

S

Pump motor stalled

T

Safe mode communications time out

E

Pumping Program error

O

Pumping Program Phase is out of range

=> [ ]

Pump network address, 0 to 99

*

System command (overrides network address)

=>

Response to command

=> (0x0D)

Carriage return

=> (0x02)

Start of packet transmission indicator

=> (0x03)

End of packet transmission indicator

=>

16 bit CCITT CRC of (high byte, low
byte)

=>

Number of bytes remaining in packet, including this byte

8.3.5

Network Command Burst

The Network Command Burst feature is only applicable when communicating to a network of pumps.

This special feature allows commands to be sent to a network of pumps simultaneously. For example,
changing the pumping rates simultaneously on a network of pumps.

Note: Since this special feature violates the general communications protocol of one command-one response,
all of the pumps will be responding simultaneously, and therefore the communications response to a Network
Command Burst will be gibberish and should be ignored.

Command Format
Command Burst => *
Network Command Burst => < Command Burst > [Network Command Burst]

Where indicates the address of the pump that is to execute . Maximum address is 9.
n => {0 ... 9}

Example: Change the pumping rates of the 3 pumps on a pump network as follows:

Pump 0: 100 mL/hr
Pump 1: 250 mL/hr
Pump 2: 375 mL/hr
