CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 9
NO. PART NO. PART NAME QTY. REMARKS
1 10657 PITCH CONTROL HANDLE 1
2 10881 LATCHING BAR 1
3 3910382 SHOULDER BOLT 3/8 X 3/8 1
4 10655 LATCH RETURN SPRING COVER 1
5 10654 LATCH RETURN SPRING 1
6 10659 QP LATCHING BOLT 1
6 10878 QP LATCHING BOLT 1
7 0161 C LOCK WASHER 5/16” 1
8 10024 LOCK NUT 1/4- 20 1
9 1714 CABLE, PITCH CONTROL 1
10 10658 CONTROL HANDLE SUPPORT TUBE 1
11 0189 HANDLE GRIP 1
12 0304 SCREW, RHM 10- 24 X 1/4” 2
13 0302 THROTTLE ASSEMBLY CABLE 1
14 5283 LOCK NUT 5/16- 18 1
15 10651 STAR WHEEL 1
16 1456 NUT, HEX FINISH 3/8- 16 1
17 3216 COTTER PIN 3
18 0948 FLAT WASHER 1/4” 2
19 10629 HANDLE HINGE PIN 1
20 10133 LOCK NUT 3/8- 16 2
21 10136 FLAT WASHER 3/8” 3
22 20280 SUPPORT BLOCK 1
23 21017 SCREW, HHC 3/8- 16 X 3.25 FULL THRD 1
24 10701 SWING BOLT 1
25 5291 CLEVIS PIN 1
26 0300 B FLAT WASHER 5/16” 2
27 0669 A SCREW, HHC 5/16- 18 X 2-1/4” 1
28 1512 CLUTCH HAND LEVER 1
29 1493 SCREW, HHC 3/8 - 16 X 3.25 1
30 10036 CLUTCH ASSIST HANDLE ASSY. 1
31 10660 SHIM 1
32 3164 SCREW, FHSC 1/4- 20 X 1” 1
33 21438 LOWER HANDLE 1
34 10635 UPPER HANDLE 1
35 10653 CLUTCH CABLE ASSY. 1
36 10676 ACORN NUT 5/16- 18 1
37 8128 CLAMP 2
39 11015 HANDLE SLIDER 1
QUICK PITCH ™ ™ ™ ™ ™ HANDLE ASSY.
