CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 17
ENGINE ASSY., 4 HP HONDA (S/N CL0132685 AND ABOVE)
NO. PART NO. PART NAME QTY. REMARKS
1 0105 SCREW, HHC 5/16- 18 X 1-1/2 3
2 0131 A SCREW, HHC 1/4 - 20 X 3/4 3
3 0161 C LOCK WASHER 5/16 6
4 0166 A LOCK WASHER 3/8 1
5 0181 B LOCK WASHER 1/4 3
6 0300 B FLAT WASHER 5/16 9
7 0948 FLAT WASHER 1/4 7
8 0949 HEX NUT 1/4- 20 5
9 1273 SCREW, HHST 3- 32 X 3/8 2
10 1284 SCREW, HHC 3/8 -16 X 1-1/2 2
11 1391 SCREW, HHC 5/16 - 24 X 1-1/2 ZINC 1
12 1512 CONTROL LEVER, HAND CLUTCH 1
13 1672 SCREW, HHC 3/8 -24 X 1 2
14 1733 WASHER, 1/2 X 1/32 1
15 1834 DEFLECTOR, HONDA EXHAUST 1
16 1897 SPACER 1
17 2343 BELT (A25) 1
18 4538 SCREW, HHC 1/4- 20 X 2-1/2 1
19 6014 C NUT, HEX 5/16 X 24 1
20 10136 FLAT WASHER 3/8 1
21 10181 SCREW, HHC 5/16 - 24 X 1-1/4 3
22 10450 SHS 10- 32 X 1/4 1
23 10608 PULLEY, IDLER 1
24 10909 SQUARE KEY 3/16 X 11/16 1
25 10936 CABLE ASSY., HAND CLUTCH 1
26 11043 PULLEY, AK41 X 3/4 1
27 13351 WASHER, FLAT USS 3/8 EXT. THK. 1
28 19380 SCREW, HHC 1/4 - 20 X 3 2
29 20977 CLUTCH LEVER 1
30 20981 SHOE, BELT HAND CLUTCH 2
31 21387 ENGINE, 4 HP. HONDA GX120K1QX2/UT1QX2 1
32 21674 BRACKET, PULLEY GUARD 1
33 21675 PULLEY AK-32 X 3/4 1
34 21713 CLUTCH BRACKET 1
35 30102-001 BELT GUARD ...................................................... 1 ......... SAFETY ITEM
36 933242 WASHER, FLAT SAE 3/8 GRD 9 YZ 2
