CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 23
HONDA GX120K1QX2/UT1QX2 ENGINE — AIRCLEANER (DUAL) ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
AIRCLEANER (DUAL) ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16271ZE1000 GASKET, ELBOW 1
2 17210ZE0505 ELEMENT, AIR CLEANER (DUAL) ....................1................INCLUDES ITEMS W/ $
2 17210ZE0822 ELEMENT, AIR CLEANER (DUAL) ....................1................INCLUDES ITEMS W/ $
3$ 17218ZE0505 FILTER, OUTER 1
3$ 17218ZE0820 FILTER, OUTER 1
4 17230ZE0820 COVER, AIR CLEANER (DUAL) 1
5$ 17232891000 GROMMET, AIR CLEANER 1
7# 17238ZE0010 COLLAR, AIR CLEANER 2
8# 17239ZE1000 COLLAR B, AIR CLEANER 1
9 17410ZE0030 ELBOW, AIR CLEANER ....................................1................INCLUDES ITEMS W/ #
12 90325044000 WINGNUT, TOOL BOX SETTING 2
13 957010602000 BOLT, FLANGE 6X20 1
14 9405006000 NUT, FLANGE 6MM 2
