CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 13
GEARBOX ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1% * 0753 SEAL, OIL NATIONAL 1
2% 0131 A SCREW, HHC 1/4-20 X 3/4 4
3% 12876 FLANGE, INPUT SHAFT 1
4% * 20395 RING, O -139 BUNA N 1
6%# 21218 BEARING, CUP, TIMKEN 2
7%# 20465 BEARING, CONE, TIMKEN 2
8% 0627 KEY, SQUARE 3/16 X 1 1/4 1
9% 1851 GEAR, WORM & SHAFT ASSY. 1
10% 21454 CASE, GEAR 1
11% 21218 VENT, AIR 1
12 21046 GASKET/SEAL KIT .......................................................... 1 ....... INCLUDES ITEMS W/ *
13 21047 BEARING KIT ................................................................... 1 ....... INCLUDES ITEMS W/ #
14% 20476 SCREW, HHC 1/4-28 X 3/8 2
15% 21033 SIGHT GLASS, 3/4 M PIPE STEEL 1
16% 0121 A FITTING, PLUG 3/8 MP SQ HEAD 1
17% 1138 RING, SNAP, TRUARC 5100-112 1
18%# 20475 BEARING, CUP TIMKEN 2
19%# 20474 BEARING, CONE TIMKEN 2
20% 1140 GEAR, WORM, BRONZE 1
21% 21435 SHAFT, OUTPUT 1
22% 1139 KEY, WOODRUFF #21 HARDENED 1
23% 1238 KEY, WOODRUFF #25 1
25% * 20396 RING, O -257 BUNA N 1
26% 12875 COVER, GEARBOX 1
27% 10235 WASHER, C/S EXT. SHKP 4
28% 1146 SCREW, FHSC 5/16-18 X 1, NYLOC NP 4
29% * 0254 SEAL, OIL, NATIONAL 1
30 21436 GEARBOX ASSY. ............................................................. 1 ....... INCLUDES ITEMS W/ %
31 10139 LUBE, GEARBOX OIL ISO 680, 22 OZ. (650 mL) ............ 2 ....... REQUIRES 27 OZ. (798 mL)
