CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 27
HONDA GX120K1QX2/UT1QX2 ENGINE — CARBURETOR ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
CARBURETOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1$ 16010ZE1812 GASKET SET 1
2$ 16011ZE0005 VALVE SET, FLOAT 1
3 16013ZE0005 FLOAT SET 1
3 16013Z0SB01 FLOAT SET 1
4 16015ZE1811 CHAMBER SET, FLOAT, BE60B A 1
4 16015ZE1831 CHAMBER SET, FLOAT, BE60B B 1
4 16015ZE0831 CHAMBER SET, FLOAT 1
5$ 16016ZH7W01 SCREW SET, PILOT 1
6$ 16024ZE1811 SCREW SET, DRAIN 1
7$ 16028ZE0005 SCREW SET B 1
8$ 16044ZE0005 CHOKE SET, BE12A B 1
9 16100ZH8W50 CARBURETOR ASSY. (BE65B A) .....................1................S/N 2728507 AND BELOW
.............................................................................................INCLUDES ITEMS W/ $
9 16100ZH8W51 CARBURETOR ASSY. (BE65B B) .....................1................S/N 3491425 AND ABOVE
.............................................................................................INCLUDES ITEMS W/ $
9 16100Z0S921 CARBURETOR ASSY. (BE60R A) .....................1................INCLUDES ITEMS W/ $
10$ 16124ZE0005 SCREW, THROTTLE STOP 1
11$ 16166ZH7W50 NOZZLE, MAIN BE12A B 1
12$ 16173001004 PACKING, FUEL STRAINER CUP 1
13 16211ZE1000 INSULATOR, CARBURETOR 1
14 16212ZH7800 GASKET, INSULATOR 1
15 16220ZE1020 SPACER, CARBURETOR 1
16 16221ZH8800 GASKET, CARBURETOR ..................................1................S/N 2533057 AND BELOW
16 16221ZH8801 GASKET, CARBURETOR ..................................1................S/N 2534177 AND ABOVE
16 16221ZH8801 GASKET, CARBURETOR 1
17 16610ZE1000 LEVER, CHOKE (STD) ......................................1................INCLUDES ITEMS W/ #
18$ 16953ZE1812 LEVER, VALVE 1
19$ 16954ZE1811 PLATE, LEVER SETTING 1
20$ 16956ZE1811 SPRING, VALVE LEVER 1
21$ 16957ZE1812 GASKET, VALVE 1
22$ 16967ZE0811 CUP, FUEL STRAINER 1
23$ 93500030080G SCREW, PAN (3 X 6) 2
23$ 93500030061H SCREW, PAN (3 X 6) 2
24# 9430520122 PIN, SPRING (2 X 12) 1
25 99101ZH80550 JET, MAIN (#55) OPTIONAL 1
25 99101ZH80580 JET, MAIN (#58) OPTIONAL 1
25$ 99101ZH80600 JET, MAIN (#60) 1
26$ 99204ZE00350 JET, SET, PILOT (#35) 1
