CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 43
HONDA GX120K1QX2/UT1QX2 ENGINE — FUEL TANK ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16854ZH8000 RUBBER, SUPPORTER 107MM 1
2 16955ZE1000 JOINT, FUEL TANK 1
3 17510ZE0020ZD TANK, FUEL *NH1* (BLACK) 1
3 17510Z0S000ZB TANK, FUEL *NH31* (BLACK) ...........................1................S/N 1219127 AND BELOW
3 17510Z0S010ZB TANK, FUEL *NH31* (BLACK) ...........................1................S/N 1219127 AND ABOVE
5 17620ZH7023 CAP, FUEL FILLER ............................................1................INCLUDES ITEMS W/ $
5 17620Z0T813 CAP, FUEL FILLER (CHROME PLATED) ..........1................S/N 1120058 AND BELOW
.............................................................................................INCLUDES ITEMS W/ $
5 17620Z4H000 CAP, FUEL FILLER ............................................1................S/N 1120059 TO 1188057
.............................................................................................INCLUDES ITEMS W/ $
5 17620Z4H010 CAP, FUEL FILLER ............................................1................S/N 1188058 TO 1206680
.............................................................................................INCLUDES ITEMS W/ $
5 17620Z4H020 CAP, FUEL FILLER ............................................1................S/N 1206681 AND ABOVE
.............................................................................................INCLUDES ITEMS W/ $
6$ 17631ZH7003 GASKET, FUEL FILLER CAP 1
6$ 17631Z4H800 GASKET, FUEL FILLER CAP ............................1................S/N 1188057 AND BELOW
6$ 17631Z4H800 GASKET, FUEL FILLER CAP ............................1................S/N 1188058 TO 1206680
6$ 17631Z0T801 GASKET, FUEL FILLER CAP ............................1................S/N 1206681 AND ABOVE
11$ 91353671003 O- RING 13.5X1.5 (ARAI) 1
11$ 91353671004 O- RING 13.5X1.5 (ARAI) 1
12 9405006000 NUT, FLANGE 6MM 2
13 950014500360M BULK HOSE, FUEL (4.5X3000) (4.5X140) 1
14 9500202080 CLIP, TUBE (B8) 2
14 9500202080 CLIP, TUBE (B8) .................................................2................S/N 1038089 AND BELOW
14 950024080008 CLAMP, TUBE (D8) ............................................2................S/N 1038090 AND ABOVE
15 90004ZH7003 BOLT, FLANGE 6X29 1
