CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 49
HONDA GX120K1QX2/UT1QX2 ENGINE — PISTON ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
PISTON ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 13010ZK7V01 RING SET, PISTON (STANDARD) 1
1 13010Z4F004 RING SET, PISTON (STANDARD) 1
1 13011ZK7V01 RING SET, PISTON (OS 0.25), OPTIONAL 1
1 13011Z4F004 RING SET, PISTON (OS 0.25), OPTIONAL 1
1 13012ZK7V01 RING SET, PISTON (OS 0.50), OPTIONAL 1
1 13012Z4F004 RING SET, PISTON (OS 0.50), OPTIONAL 1
1 13013ZK7V01 RING SET, PISTON (0.75), OPTIONAL 1
1 13013Z4F004 RING SET, PISTON (0.75), OPTIONAL 1
2 13101ZH7000 PISTON, STANDARD ........................................................ 1 ......S/N 3993725 AND BELOW
2 13101ZH7010 PISTON, STANDARD ........................................................ 1 ......S/N 3993726 AND ABOVE
2 13101Z0S810 PISTON, STANDARD ........................................................ 1 ......S/N 1120058 AND BELOW
2 13101Z0S811 PISTON, STANDARD ........................................................ 1 ......S/N 1120059 TO 1141323
2 13101ZH7020 PISTON, STANDARD ........................................................ 1 ......S/N 1141324 AND ABOVE
2 13102ZH7000 PISTON, OS 0.25 (OPTIONAL) ........................................ 1 ......S/N 3993725 AND BELOW
2 13102ZH7010 PISTON, OS 0.25 (OPTIONAL) ........................................ 1 ......S/N 3993726 AND ABOVE
2 13102Z0S810 PISTON, OS 0.25 (OPTIONAL) ........................................ 1 ......S/N 1120058 AND BELOW
2 13102Z0S811 PISTON, OS 0.25 (OPTIONAL) ........................................ 1 ......S/N 1120059 TO 1141323
2 13102ZH7020 PISTON, OS 0.25 (OPTIONAL) ........................................ 1 ......S/N 1141324 AND ABOVE
2 13103ZH7000 PISTON, OS 0.50 (OPTIONAL) ........................................ 1 ......S/N 3993725 AND BELOW
2 13103ZH7000 PISTON, OS 0.50 (OPTIONAL) ........................................ 1 ......S/N 3993726 AND ABOVE
2 13103Z0S810 PISTON, OS 0.50 (OPTIONAL) ........................................ 1 ......S/N 1120058 AND BELOW
2 13103Z0S811 PISTON, OS 0.50 (OPTIONAL) ........................................ 1 ......S/N 1120059 TO 1141323
2 13103ZH7020 PISTON, OS 0.50 (OPTIONAL) ........................................ 1 ......S/N 1141324 AND ABOVE
2 13104ZH7000 PISTON, 0.75 (OPTIONAL) .............................................. 1 ......S/N 3993725 AND BELOW
2 13104ZH7010 PISTON, 0.75 (OPTIONAL) .............................................. 1 ......S/N 3993726 AND ABOVE
2 13104Z0S810 PISTON, 0.75 (OPTIONAL) .............................................. 1 ......S/N 1120058 AND BELOW
2 13104Z0S811 PISTON, 0.75 (OPTIONAL) .............................................. 1 ......S/N 1120059 TO 1141323
2 13104ZH7020 PISTON, 0.75 (OPTIONAL) .............................................. 1 ......S/N 1141324 AND ABOVE
3 13111ZE0000 PIN, PISTON 1
4 132A0ZE0000 ROD ASSY., CONNECTING (UNDERSIZE) OPTIONAL . 1 ......INCLUDES ITEMS W/ $
4 13200ZE0000 ROD ASSEMBLY, CONNECTING ..................................... 1 ......INCLUDES ITEMS W/ $
4 13200Z0S800 ROD ASSEMBLY, CONNECTING ..................................... 1 ......INCLUDES ITEMS W/ $
5$ 90001ZE1000 BOLT, CONNECTING ROD 2
6 90551ZE0000 CLIP, PISTON PIN 13MM 2
