CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 25
HONDA GX120K1QX2/UT1QX2 ENGINE — CAMSHAFT ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
CAMSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 14100ZE0812 CAMSHAFT ASSEMBLY ...................................1................INCLUDES ITEMS W/ $
2 14410ZE0010 ROD, PUSH 2
3 14431ZE1000 ARM, VALVE ROCKER 2
4 14441ZE1010 LIFTER, VALVE 2
5 14451ZE1013 PIVOT, ROCKER ARM 2
6$ 14568ZE1000 SPRING, WEIGHT RETURN 1
7 14711ZF0010 VALVE, INTAKE 1
8 14721ZH7810 VALVE, EXHAUST 1
8 14721ZH7810 VALVE, EXHAUST 1
9 14751ZF1000 SPRING, VALVE 2
10 14771ZE1000 RETAINER, IN. VALVE SPRING 1
11 14773ZE1000 RETAINER, EX. VALVE SPRING 1
12 14781ZE1000 ROTATOR, VALVE 1
13 14791ZE0010 PLATE, PUSH ROD GUIDE 1
14 90012ZE0010 BOLT, PIVOT 8MM 2
15 90206ZE1000 NUT, PIVOT ADJ. 2
16 12209ZH8003 SEAL, VALE STEM 1
