CA4HM WALK-BEHIND TROWEL — PARTS MANUAL — REV. #4 (11/03/10) — PAGE 51
HONDA GX120K1QX2/UT1QX2 ENGINE — RECOIL STARTER ASSY.
NOTICE
GX120K1QX2: AUGUST 2008 AND BELOW
GX120UT1QX2: SEPTEMBER 2008 AND ABOVE
RECOIL STARTER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 28400ZH8013ZB STARTER ASSY., RECOIL *NH1* (BLACK) ..... 1 ...............INCLUDES ITEMS W/$
1 28400ZH8013ZA STARTER ASSY., RECOIL *R8* (RED) .............1................S/N 4142273 AND BELOW
.............................................................................................INCLUDES ITEMS W/$
1 28400ZH8013YA STARTER ASSY., RECOIL *R280* (RED) .........1................S/N 4142274 AND ABOVE
.............................................................................................INCLUDES ITEMS W/$
1 28400ZH8023YA STARTER ASSY., RECOIL *R280* (RED) .........1................INCLUDES ITEMS W/ $
2$ 28410ZH8003ZB CASE, RECOIL STARTER *NH1* (BLACK) 1
2$ 28410ZH8003ZA CASE, RECOIL STARTER *R8*(RED) .............1................S/N 4142273 AND BELOW
2$ 28410ZH8003YA CASE, RECOIL STARTER *R280* (RED) .........1................S/N 4142274 AND ABOVE
2$ 28410ZH8003YA CASE, RECOIL STARTER *R280* (RED) 1
3$ 28420ZH8013 REEL, RECOIL STARTER 1
3$ 28420ZH8801 REEL, RECOIL STARTER 1
4$ 28422ZH8013 RATCHET, STARTER 2
4$ 28422ZH8801 RATCHET, STARTER 2
5$ 28433ZH8003 GUIDE, RATCHET 1
5$ 28433ZH8801 GUIDE, RATCHET 1
6$ 28441ZH8003 SPRING, FRICTION 1
6$ 28441ZH8801 SPRING, FRICTION 1
7$ 28442ZH8003 SPRING, RECOIL STARTER 1
8$ 28443ZH8003 SPRING, RETURN 2
8$ 28443ZH8801 SPRING, RETURN 2
9$ 28461ZH8003 GRIP, RECOIL STARTER 1
10$ 28462ZH8003 ROPE, RECOIL STARTER 1
11$ 90003ZH8003 SCREW, SETTING 1
12 90008ZE2003 BOLT, FLANGE 6X10 3
